R911324310 (MKD112C-058-KP0-RN)

MKD Synchronous Motors

Rated 5 stars (6 total reviews)

In Stock, Ships 2-3 Days

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone

Part Number

+Add a message

Message

Request a Replacement

Request a Repair

Quote Both

Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping

Phone:
1-888-551-3082

Email:
[email protected]

The R911324310 (MKD112C-058-KP0-RN) is an electric servo motor by Bosch Rexroth featuring a centring diameter of 130 mm and a frame size of 112, which indicates its mechanical dimensions, including a 192 mm flange. It delivers continuous torque at standstill and cools via natural convection. The motor's winding code is 058, determining the output data in combination with its frame size and length. Featuring an absolute integrated encoder system, this model gives precise position and speed control. The R911324310 (MKD112C-058-KP0-RN) is connected through an output shaft with a keyway design, in line with DIN 6885 regulations. This 45 kgs servo motor does not have a holding brake but has a peak current rating of 239 Amperes. The power connector is right-oriented, and the motor performs optimally at 60K housing and 100K winding overtemperature, beyond which performance may decline. This globally shippable unit comes with a one-year manufacturer's warranty.

Technical Specifications

Centring Diameter
130 mm

Frame Size
192 mm

Frame Length
C

Cooling Method
Natural Convection

Equivalent Frame Length
38 Nm

Winding Code
058

Encoder System
RSF with absolute integrated

Positional detection
4,096 revs

Output Shaft Design
Keyway design as per DIN 6885

Motor Weight
45 kg

Peak Current Rating
239 Amperes

Power Connection Direction
Right

Performance Type
Standard

Housing Overtemperature
60K

Winding Overtemperature
100K

Shipping Availability
Global
