R911265231 (SOT02-E2A-FW)

SOT Operator Panels

  In Stock, Shipping Varies
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
+Add a message
Expedited Lead Times on Select Parts
1 Year Warranty Included
Free Ground Shipping
The R911265231 (SOT02-E2A-FW) is an operator control panel developed for integration with Bosch Rexroth DLC systems. It interfaces with the DLC via RS485 communication over distances up to 1000 meters. The unit utilizes convection cooling and includes a 16-line non-glare LCD with a CCFL backlight for data display. It supports a maximum operating humidity of 95% RH and is rated for operation between 5 °C and +45 °C, with storage and transport ranges between -30 °C and +85 °C, and installation up to 1000 meters above sea level. The panel provides parameter monitoring, operational and fault status display—including indication of DLC system faults, parameter loss, and operation modes such as self-test and parameter mode. Functions and interface screens can be configured via Screen Manager software.

Technical Specifications

Product Type
Operator Control Panel

Compatible Systems
DLC System

Connectivity
RS485 Cable

Maximum Connection Distance
1000 meters

Status Displays
Machine Parameters, Operating Status, Fault Status

Modes Indicated
Self-Test Mode, Parameter Mode

Additional Messages
Cycle Stop, Feeding, No Cycle Start.
